Construction of Terpinen-4-ol Encapsulation System Based on <i>β</i>-Cyclodextrin-based Metal-organic Framework

SONG Jiaxuan; HAN Chenrui; WANG Yubei; CAO Jiankang

doi:10.13386/j.issn1002-0306.2023100247

Volume 45 Issue 18

Sep. 2024

Turn off MathJax

Article Contents

Abstract

References

Supplements

Science and Technology of Food Industry > 2024 > 45(18): 88-94. > DOI: 10.13386/j.issn1002-0306.2023100247

SONG Jiaxuan, HAN Chenrui, WANG Yubei, et al. Construction of Terpinen-4-ol Encapsulation System Based on β-Cyclodextrin-based Metal-organic Framework[J]. Science and Technology of Food Industry, 2024, 45(18): 88−94. (in Chinese with English abstract). doi: 10.13386/j.issn1002-0306.2023100247.

Citation:

PDF (1765 KB)

Construction of Terpinen-4-ol Encapsulation System Based on β-Cyclodextrin-based Metal-organic Framework

College of Food Science and Nutritional Engineering, China Agricultural University, Beijing 100083, China

More Information

Received Date: October 31, 2023
Available Online: July 11, 2024

Graphical Abstract

Abstract

Abstract

In order to improve the hydrophobicity and volatility of terpinen-4-ol and extend its duration of action, β-cyclodextrin-based metal-organic framework (β-CD-MOF) was first prepared by the modified vapor diffusion method, and then terpinen-4-ol was encapsulated with the β-CD-MOF to prepare a terpinen-4-ol/β-CD-MOF inclusion complex by the solvent incubation method. The mass ratio of the prepared β-CD-MOF or β-CD used as the control to terpinen-4-ol was optimized for encapsulation. The morphological characteristics, spectral absorption properties and thermogravimetric characterisation of the terpinen-4-ol/β-CD-MOF complex were analyzed. Through in vitro bacteriostatic assays, the inhibitory effects of the complex on three food-borne pathogens were determined. The results showed that the highest drug loading and encapsulation efficiency were achieved when the mass ratio of terpinen-4-ol to β-CD-MOF was 1:1, superior to the same preparation conditions using β-CD as a carrier. Scanning electron microscope (SEM) observations indicated that irregularly arranged β-CD molecules stacked together under the bridging action of K⁺, forming an orderly arranged rectangular β-CD-MOF. Fourier-transform infrared spectroscopy (FTIR) and X-ray diffraction (XRD) analysis demonstrated terpinen-4-ol was successfully encapsulated in β-CD-MOF with hydrogen bond interactions between them. Thermogravimetric analysis (TGA) proved that the volatilization rate of terpinen-4-ol could be retarded when encapsulated by β-CD-MOF, extending its application temperature range from 30~160 ℃ to 30~350 ℃. In vitro antibacterial experiments showed that the terpinen-4-ol/β-CD-MOF complex exhibited long-lasting antibacterial abilities against three common cold-chain microorganisms, including Escherichia coli, Staphylococcus aureus and Listeria monocytogenes. In conclusion, encapsulating terpinen-4-ol in β-CD-MOF allows for effective preservation, providing a theoretical basis for the development of novel, green and safe antimicrobial materials for cold-chain applications.
- β-CD-MOF,
- terpinen-4-ol,
- encapsulation,
- characterization,
- stability,
- antibacterial activity

FullText(HTML)

References (31)

References

[1]	霍若冰, 李洋, 徐曈晖, 等. 鱼腥草提取液-壳聚糖抗菌复合膜对低温贮藏蓝莓的保鲜作用[J]. 现代食品科技,2022,38(8):153−162. [HUO R B, LI Y, XU T H, et al. Freshness preservation of blueberries stored at low temperatures by Fritillaria extract-chitosan antimicrobial composite film[J]. Modern Food Science and Technology,2022,38(8):153−162.] HUO R B, LI Y, XU T H, et al. Freshness preservation of blueberries stored at low temperatures by Fritillaria extract-chitosan antimicrobial composite film[J]. Modern Food Science and Technology, 2022, 38（8）: 153−162.
[2]	杜清, 钟雨樨, 杨明, 等. 松油烯-4-醇的药理作用研究进展[J]. 中国实验方剂学杂志,2023,29(14):265−271. [DU Q, ZHONG Y X, YANG M, et al. Progress of pharmacological effects of Pinene-4-ol[J]. Chinese Journal of Experimental Formulas,2023,29(14):265−271.] DU Q, ZHONG Y X, YANG M, et al. Progress of pharmacological effects of Pinene-4-ol[J]. Chinese Journal of Experimental Formulas, 2023, 29（14）: 265−271.
[3]	CHENG F, MO Y N, CHEN K Y, et al. Integration of metabolomics and transcriptomics indicates changes in MRSA exposed to terpinen-4-ol[J]. BMC Microbiology,2021,21(1):305. doi: 10.1186/s12866-021-02348-2
[4]	JOHANSEN B, DUVAL R E, SERGERE J C. First evidence of a combination of terpinen-4-ol and α-terpineol as a promising tool against ESKAPE pathogens[J]. Molecules,2022,27(21):7472. doi: 10.3390/molecules27217472
[5]	CORDEIRO L, FIGUEIREDO P, SOUZA H, et al. Terpinen-4-ol as an antibacterial and antibiofilm agent against staphylococcus aureus[J]. International Journal of Molecular Sciences,2020,21(12):4531. doi: 10.3390/ijms21124531
[6]	ZHAO L J, DUAN F X, GONG M, et al. (+)-Terpinen-4-ol inhibits bacillus cereus biofilm formation by upregulating the interspecies quorum sensing signals diketopiperazines and diffusing signaling factors[J]. Journal of Agricultural and Food Chemistry,2021,69(11):3496−3510. doi: 10.1021/acs.jafc.0c07826
[7]	王梅竹, 罗红梅, 曹煜, 等. 松油烯-4-醇对白念珠菌PLB1、SAP2基因表达的影响[J]. 贵阳医学院学报,2014,39(6):809−812. [WANG M Z, LUO H M, CAO Y, et al. Effects of pinacolen-4-ol on PLB1 and SAP2 gene expression in Candida albicans[J]. Journal of Guiyang Medical College,2014,39(6):809−812.] WANG M Z, LUO H M, CAO Y, et al. Effects of pinacolen-4-ol on PLB1 and SAP2 gene expression in Candida albicans[J]. Journal of Guiyang Medical College, 2014, 39（6）: 809−812.
[8]	瞿任, 康颖倩, 赵亮, 等. 植物精油组份松油烯-4-醇抗真菌作用研究[C]//中国菌物学会. 2012年中国菌物学会学术年会会议摘要, 2012:130. [QU R, KANG Y Q, ZHAO L, et al. Antifungal effects of the essential oil component turpentine-4-ol[C]//Chinese Society of Mycology. Abstracts of the 2012 Annual Meeting of the Chinese Mycological Society, 2012:130.] QU R, KANG Y Q, ZHAO L, et al. Antifungal effects of the essential oil component turpentine-4-ol[C]//Chinese Society of Mycology. Abstracts of the 2012 Annual Meeting of the Chinese Mycological Society, 2012: 130.
[9]	HU Z M, SHAO M, ZHANG B, et al. Enhanced stability and controlled release of menthol using a β-cyclodextrin metal-organic framework[J]. Food Chemistry,2022,374:131760. doi: 10.1016/j.foodchem.2021.131760
[10]	KANG L X, LIANG Q F, ABDUL Q, et al. Preparation technology and preservation mechanism of γ-CD-MOFs biaological packaging film loaded with curcumin[J]. Food Chemistry,2023,420:136142. doi: 10.1016/j.foodchem.2023.136142
[11]	LI H, SHI L F, LI C, et al. Metal-Organic framework based on α-cyclodextrin gives high ethylene gas adsorption capacity and storage stability[J]. ACS Applied Materials & Interfaces,2020,12(30):34095−34104.
[12]	CHEN X J, GUO T, ZHANG K K, et al. Simultaneous improvement to solubility and bioavailability of active natural compound isosteviol using cyclodextrin metal-organic frameworks[J]. Acta Pharmaceutica Sinica B,2021,11(9):2914−2923. doi: 10.1016/j.apsb.2021.04.018
[13]	QIU C, WANG J P, ZHANG H, et al. A novel approach with controlled nucleation and growth for green synthesis of size-controlled cyclodextrin-based metal-organic frameworks based on short-chain starch nanoparticles[J]. Journal of Agricultural and Food Chemistry,2018,66(37):9785−9793. doi: 10.1021/acs.jafc.8b03144
[14]	ZHAO K N, GUO T, WANG C F, et al. Glycoside scutellarin enhanced CD-MOF anchoring for laryngeal delivery[J]. Acta Pharmaceutica Sinica B,2020,10(9):1709−1718. doi: 10.1016/j.apsb.2020.04.015
[15]	XIONG Y H, WU L, GUO T, et al. Crystal transformation of β-CD-MOF facilitates loading of dimercaptosuccinic acid[J]. American Association of Pharmaceutical Scientists,2019,20(6):224−224.
[16]	张波. 环糊精金属有机框架作为活性小分子载体材料的研究[D]. 杭州:浙江大学, 2022. [ZHANG B. Cyclodextrin metal-organic frameworks as carrier materials for active small molecules[D]. Hangzhou:Zhejiang University, 2022.] ZHANG B. Cyclodextrin metal-organic frameworks as carrier materials for active small molecules[D]. Hangzhou: Zhejiang University, 2022.
[17]	刘娟. β-环糊精-钾MOF的制备及其复合材料在电化学传感中的应用研究[D]. 衡阳:南华大学, 2021. [LIU J. Preparation of β-cyclodextrin-potassium MOF and its composites in electrochemical sensing[D]. Hengyang:Nanhua University, 2021.] LIU J. Preparation of β-cyclodextrin-potassium MOF and its composites in electrochemical sensing[D]. Hengyang: Nanhua University, 2021.
[18]	BASAK Y, SERPIL S, GULUM S. Microencapsulation of wheat germ oil[J]. Journal of Food Science and Technology,2015,52(6):3590−3597.
[19]	YANG Z J, XIAO Z B, JI H B. Solid inclusion complex of terpinen-4-ol/β-cyclodextrin:kinetic release, mechanism and its antibacterial activity[J]. Flavour and Fragrance Journal,2014,30(2):179−187.
[20]	潘晓丹. 环糊精MOF材料负载百里香酚及在樱桃番茄保鲜中应用[D]. 广州:华南理工大学, 2022. [PAN X D. Cyclodextrin MOF materials loaded with thymol and its application in the preservation of cherry tomatoes[D]. Guangzhou:South China University of Technology, 2022.] PAN X D. Cyclodextrin MOF materials loaded with thymol and its application in the preservation of cherry tomatoes[D]. Guangzhou: South China University of Technology, 2022.
[21]	LI S Q, HU X X, CHEN S Y, et al. Synthesis of γ-cyclodextrin metal-organic framework as ethylene absorber for improving postharvest quality of kiwi fruit[J]. Food Hydrocolloids,2023,136:108294. doi: 10.1016/j.foodhyd.2022.108294
[22]	HARTLIEB K J, FERRIS D P, HOLCROFT J M, et al. Encapsulation of ibuprofen in CD-MOF and related bioavailability studies[J]. Molecular Pharmaceutics,2017,14(5):1831−1839. doi: 10.1021/acs.molpharmaceut.7b00168
[23]	BENEDETTO G, CLEARY B M, MORRELL C T, et al. CD-MOF-1 for CO₂ uptake:Remote and hybrid green chemistry synthesis of a framework material with environmentally conscious applications[J]. Journal of Chemical Education,2023,100(3):1289−1295. doi: 10.1021/acs.jchemed.2c00922
[24]	YU L L, WANG X X, WEI Y Y, et al. A cyclodextrin metal-organic framework loaded with terpinen-4-ol and its application to control gray mold in strawberry[J]. Food Control,2023,155:110053.
[25]	WANG Y, LI M F, WANG L, et al. Improvement of the stabilities and antioxidant activities of polyphenols from the leaves of Chinese star anise (Illicium verum Hook. f.) using beta-cyclodextrin-based metal-organic frameworks[J]. Journal of the Science of Food and Agriculture,2020,101(1):287−296.
[26]	BLIGHT B A, AHMAD T I, SHEPHERD H J, et al. Sterol uptake by an alkali-β-Cyclodextrin metal-organic framework[J]. Crystal Growth & Design,2020,20(1):43−48.
[27]	ZHANG H X, TIAN Y Q, BAI Y X, et al. Structure and properties of maize starch processed with a combination of α-amylase and pullulanase[J]. International Journal of Biological Macromolecules,2013,52:38−44. doi: 10.1016/j.ijbiomac.2012.09.030
[28]	WANG L, LIANG X Y, CHANG Z Y, et al. Effective formaldehyde capture by green cyclodextrin-based metal-organic framework[J]. ACS Applied Materials & Interfaces,2018,10(1):42−46.
[29]	YANG A H, LIU H J, LI Z D, et al. Green synthesis of β-cyclodextrin metal-organic frameworks and the adsorption of quercetin and emodin[J]. Polyhedron,2018,159:116−126.
[30]	YANG Z J, CHAI K G, JI H B. Selective inclusion and separation of cinnamaldehyde and benzaldehyde by insoluble β-cyclodextrin polymer[J]. Separation and Purification Technology,2011,80(2):209−216. doi: 10.1016/j.seppur.2011.04.017
[31]	QIN Y, WANG J P, QIU C, et al. Effects of degree of polymerization on size, crystal structure, and digestibility of debranched starch nanoparticles and their enhanced antioxidant and antibacterial activities of curcumin[J]. ACS Sustainable Chemistry & Engineering,2019,7(9):8499−8511.
